S5130S-10P-EI

336Gbps/3.36Tbps

24Mpps/102Mpps

8个10/100/1000Base-T自适应以太网端口，2个千兆SFP口

266×161 ×43.6

1个Console口

S5130S-12TP-EI

336Gbps/3.36Tbps

27Mpps/102Mpps

8个10/100/1000Base-T自适应以太网端口，4个千兆SFP口（其中两个combo口）

266×161 ×43.6

S5130S-20P-EI

336Gbps/3.36Tbps

39Mpps/102Mpps

16个10/100/1000Base-T自适应以太网端口，4个千兆SFP口

330×230 ×43.6

S5130S-28P-EI

336Gbps/3.36Tbps

51Mpps/126Mpps

24个10/100/1000Base-T自适应以太网端口，4个千兆SFP口

440×160×43.6

S5130S-28S-EI

336Gbps/3.36Tbps

108Mpps/126Mpps

24个10/100/1000Base-T自适应以太网端口，4个万兆SFP+口

440×160×43.6

S5130S-28TP-EI

336Gbps/3.36Tbps

51Mpps/126Mpps

24个10/100/1000Base-T自适应以太网端口，4个千兆SFP口（2combo口）

440×160×43.6

S5130S-52P-EI

432Gbps/4.32Tbps

87Mpps/166Mpps

48个10/100/1000Base-T自适应以太网端口，4个千兆SFP口

440×230×43.6

S5130S-52S-EI

432Gbps/4.32Tbps

144Mpps/166Mpps

48个10/100/1000Base-T自适应以太网端口，4个万兆SFP+口

440×230×43.6

S5130S-52TP-EI

432Gbps/4.32Tbps

87Mpps/166Mpps

48个10/100/1000Base-T自适应以太网端口，4个千兆SFP口（2combo口）

440×230×43.6

S5130S-52ST-EI

432Gbps/4.32Tbps

144Mpps/166Mpps

48个10/100/1000BASE-T自适应以太网端口，2个10G BASE-X SFP+端口,2个1/2.5/5/10G BASE-T电口

440×260×43.6

S5130S-28ST-EI

336Gbps/3.36Tbps

108Mpps/126Mpps

24个10/100/1000BASE-T自适应以太网端口，2个10G BASE-X SFP+端口,2个1/2.5/5/10G BASE-T电口

440×160×43.6

S5130S-28F-EI

336Gbps/3.36Tbps

108Mpps/126Mpps

24个100/1000 SFP光口（其中有8个combo口），4个10G/1G BASE-X SFP+端口

440×360 ×43.6
